Caravan Shade Shed
Compact Coverage. Serious Protection. Delivered Free.
Choose options
product info
Designed specifically for caravans or trailers, the TSS Caravan Shade Shed is made to order using our patented, no-rust frame and durable Colorbond® sheeting. With certified engineering drawings included, it’s the no-fuss solution for protecting your investment from the elements.
Quick to install with our slip-fit connection system — no cutting or welding required. Anchoring options are available for all ground types, with Australia-wide delivery.
Please note: This product is not cyclone rated. If you need cyclone rated, check out our Cyclonic Caravan Shade Shed.
The Shade Shed — Built for Aussie caravans. Delivered ready.
*Please note, some images shown may include optional additional sheeting to rear and side walls. Standard roof sheeting extends
400mm past the shoulder of the frame only. Extra cost applies.
SHADE SHEDS SIGNATURE
GROUNDING OPTIONS
CONCRETE PIER KIT
Concrete Piers are used for securing semi-permanent structures.
ALUMINinium GROUND ANCHORS
Aluminium Ground Anchors are our most popular grounding option. They are light, rust free and easy to install. Each Ground Anchor comes with a bracket, nuts and bolts to secure the Base Rail of the Shade Shed to the anchor.
SADDLE WITH DYNABOLTS
The Saddle and Dynabolts are used for securing structures to a concrete slab.
EDGE SADDLE WITH DYNABOLTS
The Edge Saddle and Dynabolts are used for securing structures to the edge of a concrete slab.
Nationwide Delivery
Transportable Shade Sheds Australia provides reliable delivery services across the country. Our efficient packaging and logistics processes help ensure your shed is transported safely and arrives ready for customer installation.
Size Not Right?
Request A Free Quote
Don't see the size you're after, don't worry. We have more options available including a complete custom shade shed. Get in touch today
AUSTRALIAN MADE
All Transportable Shade Sheds products are proudly Australian-made. Every component is manufactured in Australia using high-quality, fully galvanised steel that’s designed to withstand Australia’s harsh conditions. Our sheds are locally engineered, locally produced, and locally supported — ensuring reliable durability, faster delivery times, and consistent quality control throughout the entire process. Choosing TSS means supporting Australian manufacturing and receiving a product built specifically for Australian conditions.
DIY INSTALLATION
DIY Install
Our shade sheds are supplied as pre-engineered, easy-to-assemble kits designed for straightforward DIY installation. Each kit arrives with all required components and clear instructions, allowing customers to install their shed without specialised tools or the need for a concrete slab.
Optional anchoring systems are available for added stability depending on site conditions. Thanks to our slip-fit (swaged) design, assembly is quick, simple, and secure.
Tools Required
- Impact driver
- Tape measure
- Level or string line
- Sledgehammer (if using Ground Anchors)
- Tin snips (for flashing)
Tip: Lay out all parts first and check your site is reasonably level before starting.
Base Rails & Portal Frames
1) Build the Base Rails (Slip-Fit)
Shed construction starts at the base rails. Some rails have swaged (reduced) ends that slip inside the next rail — this is our slip-fit system.
Slide each swaged end into the next rail and ensure everything is aligned. Secure every slip-fit connection with screws on both sides before moving to the next rail.
2) Grounding (If Selected)
If you’ve chosen a grounding option, place anchors beside the base rail between portal positions, mark the locations, then move the rail aside and drive the anchors into the ground.
Reposition the base rail over the anchors and fasten the saddle brackets down to secure the rail.
3) Assemble Portal Frames
Assemble each portal frame by slipping the swaged ends together. Depending on your shed design, this may include pitched pillars, apex, risers, and rafters.
Check your frame is square by measuring across the top and bottom. Secure each connection with screws on both sides.
Riser Kit & Rafters
1) Optional Riser Kit
When building on uneven ground, the optional riser kit helps level the shed. Run a string line across the base rails and adjust the risers until the string sits level.
Measure from the string line down to the base rail to confirm the correct rise needed.
2) Square Up & Install Portals
Install the front and rear portal frames first. Adjust the base rails so the top and bottom widths match, then take diagonal measurements.
When both diagonal measurements are equal, the shed is square. Install the remaining portal frames and use a string line along the top to ensure consistent height.
3) Rafters (If Included)
If your shed includes rafters, install them between the apex and pillars. Once aligned, secure all connections with screws.
Roofing & Flashing
1) Align the First Roof Sheet
Place the first sheet on the frame and align it so it sits straight and centred. Mark screw positions at the front, middle and rear portal frames.
2) Fix Sheets & Overlaps
Screw the first sheet to all portals. Slide the next sheet under the previous one, screw the overlap, then fasten it to the frame.
3) Flashing (If Selected)
Cut small relief cuts (~10mm) so the flashing bends cleanly. Attach from one corner and work your way around the shed.
Why Choose TSS
Transportable Shade Sheds Australia provide durable, long-lasting, and high-quality shade solutions that are designed to withstand Australia’s diverse and intense climate conditions.
We offer both non-cyclone rated (C1) and cyclone rated (C2) to suit a wide range of wind zones across Australia, with certified engineering documentation included for peace of mind. Our sheds are designed as pre-engineered kits that are easy to assemble and can be installed without the need of a concrete slab, while optional grounding systems and anchoring solutions provide added stability where required.
Because of their high-quality materials, robust design, and flexible options, Transportable Shade Sheds Australia delivers versatile, durable, and reliable shade solutions for residential, industrial, commercial, rural, and recreational applications - all backed by Australia-wide delivery and support
